GameCube
Daten und Bilder
Gamecube kaufen MPU:IBM Power PC "Gekko" Manufacturing Process: 0.18 microns Copper Wire Technology Clock Frequency: 485 MHz CPU Capacit: 925 Dmips (Dhrystone 2.1) Internal Data Precision: 32bit Integer & 64bit Floating-point External Bus Bandwidth: 1.6GB/second(Peak) (32bit address, 64bit data bus 202.5MHz) Internal Cache: L1: Instruction 32KB, Data 32KB (8 way) L2: 256KB (2 way) System LSI: "Flipper" Manufacturing Process: 0.18 microns NEC Embedded DRAM Process Clock Frequency: 202.5MHz Embedded Frame Buffer: Approx. 2MB Sustainable Latency : 5ns (1T-SRAM) Embedded Texture Cache: Approx. 1MB Sustainable Latency : 5ns (1T-SRAM) Texture Read Bandwidth: 12.8GB/second (Peak) Main Memory Bandwidth: 3.2GB/second(Peak) Color, Z Buffer: Each is 24bits Image Processing Function: Fog, SubpixelAnti-aliasing, HW Light x8, Alpha Blending, Virtual Texture Design, Multi-textureMapping/Bump/Environment Mapping, MIPMAP, Bilinear Filtering, Real-time Texture Decompression(S3TC), etc. Other: Real-time Decompression of Display List,HW Motion Compensation Capability (The following sound related functions are allincorporated into the System LSI) Sound Processor: Special 16bit DSP Instruction Memory: 8KB RAM + 8KB ROM Data Memory: 8KB RAM + 4KB ROM Clock Frequency: 101.25 MHz Maximum Number of Simultaneously Produced Sounds:ADPCM: 64ch Sampling Frequency: 48KHz System Floating-point Arithmetic Capability:13.0GFLOPS (Peak) (MPU, Geometry Engine, HW Lighting Total) Actual Display Capability: 6 million to12 million polygons/second (Display capability assuming actual game with complexitymodel, texture, etc.) System Main Memory: 24MB SustainableLatency : 10ns or lower (1T-SRAM) A-Memory: 16MB (100MHz DRAM) Disc Drive: CAV (Constant AngularVelocity) System Average Access Time Data Transfer Speed 16Mbps to25Mbps 128ms Media: 8cm NINTENDO GAMECUBE Disc basedon Matsushita's Optical Disc Technology Approx. 1.5GB Capacity Input/Output: Controller Port x4,Digicard Slot x2, Analog AV Output x1, Digital AV Output x1, High-Speed Serial Port x2,High-speed Parallel Port x1 Power Supply: AC Adapter DC12V x 3.5A Main Unit Dimensions: 150mm(W) x 110mm(H) x161mm(D) Europa Startpreis am 03.05.2002 nur 199,- Euro Gamecube kaufen |
